Briggs & Stratton 28W700 - Manual (Page 11)

28W700
5966–11 Assemblies include all parts shown in frames. 12/1/2003
11
729 691335 Clip–Wire
(Fuel Solenoid)
729A 691224 Clip–Wire
(Starter Motor)
732 691002 Screw
(Starter Drive Cover)
733 691658 Screw
(Crankshaft Extension)
741 691284 Gear–Timing
750 691033 Screw
(Oil Pump Cover)
757 691714 Link–Counterweight
758 692423 Counterweight
759 691239 Pin–Counterweight
761 691096 Screw
(Counterweight Link)
783 693713 Gear–Pinion
(Steel Ring Gear Only)
783A 693059 Gear–Pinion
(Aluminum Ring Gear
Only)
783B 693058 Gear–Pinion
(Plastic Ring Gear
Only)
789 692037 Harness–Wiring
(Fuel Solenoid)
797 693167 Nut
(Brush Retainer)
801 691283 Cap–Drive
802 691286 Cap–End
803 693757 Housing–Starter
810 691779 Extension–Crankshaft
830 691095 Stud–Rocker Arm
842 K 691870 Seal–O Ring
(Dipstick Tube)
847 496415 Dipstick/Tube
Assembly
851 692424 Terminal–Spark Plug
868 ∅K 690968 Seal–Valve
875 696129 Base–Air Cleaner
877 393456 Wire/Connector–
Alternator
914 691108 Screw
(Rocker Cover)
921 692417 Cover–Blower Housing
934 691058 Screw
(Fan Retainer)
943 K 690589 Seal–O Ring
(Oil Pump Cover)
947 692734 Solenoid–Fuel
947A 695423 Solenoid–Fuel
950 691657 Screw–Float Bowl
965 499613 Cover–Oil Pump
967 272403 Filter–Pre Cleaner
968 692139 Cover–Air Cleaner
969 691108 Screw
(Blower Housing
Cover)
969A 690365 Screw
(Blower Housing
Cover)
971 692129 Screw
(Air Cleaner Base
to Carburetor)
975 495933 Bowl–Float
975A 695417 Bowl–Float
977 690192 Gasket Set–Carburetor
977A 695428 Gasket Set–Carburetor
987 D 691326 Seal–Throttle Shaft
987A D 698777 Seal–Throttle Shaft
996 690678 Shield–Carburetor
1005 697853 Fan–Flywheel
1006 690452 Retainer–Fan
1017 690770 Screen–Oil Pump
Used on Type No(s).
0122.
1019 496758 Kit–Label
1022 ∅K 272475 Gasket–Rocker Cover
1023 691192 Cover–Rocker
1024 499054 Pump–Oil
1026 692003 Rod–Push
(Intake)
––––––– Note –––––
692011 Rod–Push
(Exhaust)
1027 492932 Filter–Oil
1029 691751 Arm–Rocker
1032 491710 Ball–Oil Pump
1034 690822 Guide–Push Rod
1035 693784 Shaft–Pump
1036 695700 Label–Emissions
(Used After Code Date
00063000).
––––––– Note –––––
695036 Label–
Emissions
(Used After Code Date
99093000 and Before
Code Date 00070100).
694318 Label–
Emissions
(Used After Code Date
98123100 and Before
Code Date 99100100).
499364 Label–
Emissions
(Used Before Code
Date 99010100).
1051 691265 Ring–Retaining
1058 273933 Operator’s Manual
1059 698516 Kit–Screw/Washer
1090 691293 Retainer–Brush
1091 691333 Cap–Limiter
1095 691581 Gasket Set–Valve
1119 691183 Screw
(Alternator)
1127 695407 Screw
(Float Bowl)
1330 272147 Repair Manual
K Engine Gasket Set – Reference Number 358
D
Carburetor Overhaul Kit – Reference 121 & 121A
z Carburetor Gasket Set– Reference 977 & 977A
∅ Valve Gasket Set – Reference Number 1095
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
