The POSITION switch has three
settings: free, wall and
corner.
free
Use this setting if the loud speaker is
placed more than 15 cm (6") from
the wall, and no closer to a corner
than 50 cm (20") – shown by the
large light grey area in the
illustration.
wall
Use this setting if the loud speaker
is placed less than 15 cm (6") from
the wall, and no closer to a corner
than 50 cm (20") – shown by the
grey areas along the walls in the
illustration.
If the loudspeaker is mounted on a
wall bracket, use this setting.
corner
Use this setting if the loudspeaker
is placed in a corner – shown by the
dark grey areas in the illustration.
How to measure? The distances
referred to are measured as shown
here (the loud speaker seen from
above).
7
Position zones: The three settings
(free, wall and corner) correspond
to the position zones marked in
different shades of grey.
