Parts list – Bradley Smoker S19-310SS User Manual
Page 5
5
Installation
S19-310SS
Bradley Corporation • 215-533 Rev. W; ECM 10-05-022
3/15/10
Parts List
1 131-062
1 Base
2
269-237
5
Pipe Tee 1¼" NPT
3
113-583
2
Pipe 1¼" NPT x 22½"
4 S06-188
1 Plugged
Nipple
5
113-584
1
Pipe 1¼" NPT x 26½"
6
269-238
1
Pipe Plug 1-1/4" NPT
7
269-236
1
Reduc’g Bushing 1¼" to 1" NPT
8
113-006NX
1
Pipe 1" NPT x 9"
9
S30-061
1
Stay-Open Ball Valve 1" NPT
9.1
S27-276
1
1" Ball Valve with Jam Nut
9.11
161-079
1
Jam Nut only
9.2 128-142
1 Handle
10 151-001
2 Curtain
Hook
11
113-006MN
1
Pipe 1" NPT x 12"
12
169-1074
1
90º Elbow 1" NPT
13 S24-191
1 Showerhead
Assembly
13.1
S24-187
1
Flow Control Assembly, 23 GPM
14
128-156A
1
Pull Rod - 25½" Long
15
269-239
1
Reduc’g Bushing 1¼" to 1" NPT
16
113-965
2
Pipe ½" NPT x 3½"
17
269-241
2
Elbow ½" NPT
18
269-240
1
Union ½" NPT
19
113-582
1
Pipe 1¼" NPT x 6½"
20
S27-287
1
½" Ball Valve with Jam Nut
20.1
161-151
1
Jam Nut only
21 S08-338
1 Handle
Assembly
22
113-866
1
Pipe ½" NPT x 4"
23
269-242
1
90° Pipe Elbow 1¼" NPT
24
113-579
1
Pipe Nipple 1¼" NPT x 3"
25
S90-317
1
Stainless Steel Spray Ring Assy.
25.1 111-049
1
Inlet-Drain
Fitting
25.2
124-028
1
Center Seal Gasket
25.3
187-053
1
Stainless Steel Bowl
25.4 173-009
1
Cup
Strainer
25.5 S21-074
1
Supply
Pipe
25.6 113-1159
1
Spacer,
Drain
25.7 S05-131
1
Eyewash
Yoke
25.8 107-371
2
Dust
Cover
25.9 269-912
1
Swivel
Stem
25.10 124-055
2
Quad Ring
25.11
S57-148
1
Spray Ring Assembly
25.12 110-209
1
Acorn Nut
26 S45-1314SS 1 HFSO
Prepack
26.1 269-646
2
“S”
Hook
26.2
134-009A
1
Stainless Steel Chain
26.3 181-008SS
1
Treadle
26.4 160-401
1
Screw
26.5 161-137
1
Nut,
Acorn
26.6 147-026
1
Eye
Bolt
26.7 142-002BT
1
Lockwasher
26.8 161-025
1
Hex
Nut
27 114-052
1 Safety
Sign
28 204-421
1 Emergency
Inspection
Tag
29
269-915
1
Grip Pad (not shown)
30 142-002DA
1 Washer
Item Part
No.
Qty Description
Item Part
No.
Qty Description
Prepack S45-1788 includes Items 25.9, 25.10, 25.11, 25.12
