Autocue OCLED Light User Manual
On camera led light, Guide, Specifications

On Camera
LED Light
Guide
LED
120pcs white LEDs with
high brightness
Brightness
1300lx /50cm/20”
(325lx /1m) /39”
ISO100 50cm
f 8 / 1/8 S
Beam angle
60 degree
Colour
Temperature
5600
±
600K
Continuous
working hours
Approx. 3 hours
Battery lifetime
Charge for approx. 500
times
Output power
7.5W
Chargeable
voltage
AC 100-240V
Built-in Lithium
battery
Rechargeable, 3400m
AH, 3.7V
Battery charge
display
4 levels
Dimension
94 x 81 x 31mm
Weight
189g / 6.6oz
Hot shoe mount
Up / Left / Right 3pcs
Accessory
Camera bracket
Specifications
autocue.com
Combining Lights
It is possible to combine multiple lights together if required.
Slide the light into one of
the three mounting
points on the top or the
sides of the light. Then
secure in place by
tightening the locking
disc. (
A
)
A
