Page 5
3GDA Mini-Converter v1.0r3
www.aja.com
5
3GDA I/O Connections
NOTE: The Lock LED indicates valid input video by color. Green is SD video, red is HD or 3G
video, off is no input.
Installation
Typically, 3GDA installation consists of the following:
1. Connect video equipment to the BNCs.
2. Apply power to the converter (AJA power supply included).
3G/HD-SDI/SDI Input
3G/HD-SDI/SDI
+ 5 VDC
Output 5
Power
Input
BNC
BNC
3G/HD-SDI/SDI
Output 6
BNC
LOCK LED
3G/HD-SDI/SDI
Output 1
BNC
3G/HD-SDI/SDI
Output 2
BNC
3G/HD-SDI/SDI
Output 3
BNC
3G/HD-SDI/SDI
Output 4
BNC
