3GM v1.5

www.aja.com

Appendix A: Specifications

Video

Input

SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 2x BNC

Formats

3Gb, 1.5Gb, 270Mb Auto Select

See

for details.

Output

SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 3x BNC

Cable Equalization

(1694 coax)

• 270mb, 350m

• 1.5Gb, 200m

• 3Gb, 120m

Input/Output Return Loss

>15db, 270Mb - 3Gb

Audio

Input

Up to 32-channel embedded SDI audio input

• (3G-A, HD, SD only 16-ch supported)

Output

Up to 32-channel embedded SDI audio output

• (3G-A, HD, SD only 16-ch supported)

User Controls

External DIP switch

Physical

Size

4.6" x 2.4" x 1" (117 x 61 x 25 mm)

Power

Uses AJA Power Supply model DWP-U-R1 (included)

100-240V, 50/60Hz Universal Input

+5V DC regulated, 7.5 watt capacity

NOTE:

3GM is not recommended for use with AJA DRM chassis rackmount kit.
