LUT-box Mini-Converter v2.1r1
www.aja.com
22
Audio Input
Digital
• SDI embedded audio, up to 8 channels
Audio Output
Digital
• SDI embedded audio, up to 8 channels
• HDMI embedded audio, 2 or 8 channels
Analog
• 2-channel RCA-style (-10dBV nominal)
LUT File Format Support
10-bit and 12-bit 1D LUTs, and 12-bit 17 or 16 point 3D LUTs, are supported in these
formats:
1D LUT file types:
• .cube
• .lut
• .txt
3D LUT file types:
• .3dl
• .cube
• .lut
• .txt
Physical
Power
• +5 to 20V DC regulated, 8 watts max
• AJA external power supply model DWP-U-R1 (included):
• 100-240V, 50/60Hz universal input
Size
• 5.8” x 3.1” x 1” (147mm x 79mm x 25mm)
Environment
Operating Temperature :
0 to 40 degrees C (32 to 104 degrees F)
Operating Relative Humidity:
10-90% non-condensing
Operating Altitude:
<3,000 meters (<10,000 feet)
Safe Storage Temperature
(Power OFF):
-40 to 60 degrees C (-40 to 140 degrees F)
