Bosch V1160 User Manual

Page 2

2 | Day/Night color to B/W switching camera

Bosch Security Systems
P.O. Box 80002
5600 JB Eindhoven,
The Netherlands
www.boschsecuritysystems.com

Model No.

V1160P

PAL System

V1160N

NTSC System

Power

Input Voltage

12 VDC or 24 VAC (± 10 %)

Consumption

3.5 W (DC), 3.8 W (AC)

Video

Pick-up Device

PAL Model: 1/3-inch CCD imager; 795 (H) x 596 (V)

NTSC Model: 1/3-inch CCD imager; 768 (H) x 496 (V)

Scanning System

2:1 Interlace (Standard)

SYNC System

INT/Line lock

Output

1 Vp-p Composite

Minimum Illumination

0.01 lux (B/W mode), 0.5 lux (color mode), both at F1.2

Color mode

Auto1 / Auto2 / On / Off mode selectable

OSD

Camera ID, adjust menu, motion detection …

AGC

Built-in and adjustable

Backlight Compensation

Off / On (selectable weight 1 to 4)

Lens & Iris

Iris Mode

Video/DC/ESC selectable

Iris Speed

1/50 - 1/10, 000 sec selectable 11 speeds and flickerless mode

Lens Mount

Type C/CS-mount with adapter included

RS-232C

Available

S/N Ratio

> 48 dB (AGC Off)

Horizontal Resolution

520 lines in B/W mode, 480 lines in color mode

Housing

Weight

0.40 kg (0.9 lb)

Dimensions (w/o lens) [H x W x D]

50mm x 57mm x 130mm (2.24 in x 2.17 in x 5.31 in)

Environment

Operating Temperature

25.6°C to +50°C (-14°F to +122°F)
