5 Owner’s manual and assembly instructions: model 200209 outdoor patio heater 1/15/03
Contact 1-800-762-1142 for assistance.
Do not return to place of purchase.
Components Hardware
Used in
Picture Qty Description Step(s)
1 Carriage Bolt 3
12 Bolt 1 & 2
1 Large Screw 2
4 Small Screw 5
3 Dome Screw 8
12 Small Lockwasher 1 & 2
1 Large Lockwasher 3
1 Large Nut 3
1 Medium Nut 8
15 Small Nut 1, 2 & 9
1 Clip 2
1 Finial 9
1 Dome Bolt 8
1 Hex Wrench 6
