G3 Thiele-Small Parameters
Model:
G31244
G3124
G31044
G3104
Parallel
Series
Parallel
Series
Fs: (Hz)
31
31
30
35
35
35
Re: (Ohms)
1.68
6.70
3.33
1.69
6.76
3.30
Qms:
10.39 10.39 10.41
10.93 10.93 11.66
Qes:
0.65
0.65
0.79
0.60
0.60
0.70
Qts:
0.62
0.62
0.73
0.57
0.57
0.66
Vas: (Liters)
53
53
57
23
23
23
Mms: (Grams)
186
186
177
150
150
146
Cms: (µM/Newton)
144
144
154
139
139
140
Xmax: (Mm)
14.5
14.5
14.5
14.5
14.5
14.5
Xmech: (Mm)
35.0
35.0
35.0
35.0
35.0
35.0
Sd: (CM
2
)
515
515
515
345
345
345
Bl: (Tesla-M)
9.6
19.3
12.0
9.6
19.3
12.3
SPL Eff: (dB @ 1w/1m)
85.6
85.6
85.0
84.0
84.0
83.4
SPL Sen: (dB @ 2.83v)
92.4
86.4
88.8
90.8
84.7
87.3
G3 Specifications/Enclosure Recommendations
Model:
G31244
G3124
G31044
G3104
Nominal Size:
12"
12"
10"
10"
RMS Power Handling:
375w
375w
375w
375w
Impedance:
Dual 4
Ω
Single 4
Ω
Dual 4
Ω
Single 4
Ω
Frequency Response:
20-350Hz
20-350Hz
24-350Hz
24-350Hz
(+/-3dB in car)
Mounting Cutout Diameter:
11 3/16"
11 3/16"
9 1/4"
9 1/4"
(283mm)
(283mm)
(235mm)
(235mm)
Mounting Depth:
6 9/16"
6 9/16"
6 3/8"
6 3/8"
(166mm)
(166mm)
(161mm)
(161mm)
Recommended Sealed
1.0 ft
3
1.0 ft
3
0.5 ft
3
0.5 ft
3
Enclosure Volume*:
(28.3L)
(28.3L)
(14.2L)
(14.2L)
Q-Tune
™
†: (HP & Q Setting)
[email protected] [email protected]
Recommended Ported
2.0 ft
3
2.0 ft
3
1.3 ft
3
1.3 ft
3
Enclosure Volume*:
(56.6L)
(56.6L)
(36.8L)
(36.8L)
Vent Diameter:
4" (10cm)
4" (10cm)
3" (7.6cm)
3" (7.6cm)
Vent Length:
13" (33cm) 13" (33cm) 10" (25cm) 10"(25cm)
Tuning Frequency:
34Hz
34Hz
36Hz
36Hz
Q-Tune
™
†: (HP & Q Setting)
[email protected] [email protected]
[email protected] [email protected]
*Enclosure volumes include basket and port displacement
†Q-Tune
™
is a feature found on Boston GT Amplifiers
Single G3 Enclosure Design Example - Ported
Model:
G312"
G310"
H = Height:
15.5" (39.8cm)
12" (30.5cm)
W = Width:
16.5" (42.0cm)
13.25" (33.7cm)
D = Depth:
14" (35.6cm)
14" (35.6cm)
P = Port Clearance
*
:
4" (10cm)
3" (7.6cm)
Gross Volume:
2.0 Ft
3
(56.6L)
1.3 Ft
3
(36.8L)
Port Diameter:
4" (10cm)
3" (7.6cm)
Port Length:
13" (33cm)
10" (25cm)
Q-Tune
™
†
: (HP & Q)
Enclosure dimensions are internal and include basket and port displacement
This enclosure size is an example and these dimensions can be modified provided that the
exact internal volume is retained and that there is adequate space behind the vent (diameter
of port from the back and side walls)
3
⁄
4
-inch thick M.D.F. is recommended as a minimum
*Recommended distance from sides and back walls of enclosure
†Q-Tune™ is a feature found on Boston GT Amplifiers
Single G3 Enclosure Design Example - Sealed
Model:
G312"
G310"
H = Height:
10.5" (26.7cm)
7.5" (19.1cm)
W = Width:
13.0" (33.1cm)
11.0" (28.0cm)
D = Depth:
13.0" (33.1cm)
11.0" (28.0cm)
Gross Volume:
1.0 Ft
3
(28.3L)
0.5 Ft
3
(14.2L)
Q-Tune
™
†
: (HP & Q)
Enclosure dimensions are internal and include basket displacement
This enclosure size is an example and these dimensions can be modified provided that the
exact internal volume is retained
3
⁄
4
-inch thick M.D.F. is recommended as a minimum
†Q-Tune
™
is a feature found on Boston GT Amplifiers
Boston Acoustics, Inc. 300 Jubilee Drive, Peabody, MA 01960 USA
T: 978.538.5000 F: 978.538.5100 W: bostonacoustics.com
Q-Tune and SureSet are trademarks and Boston, Boston Acoustics, and the Boston Acoustics logo
are registered trademarks of Boston Acoustics, Inc.
Specifications are subject to change without notice. © 2007 Boston Acoustics, Inc.
All rights reserved. Covered by patents issued and/or pending.
1
4
2
-0
0
2
5
9
8
-0
D
W
H
D
P
W
H
B
d
6
0
6
-
2
1
-
8
1
-
4
2
-
0
3
-
6
3
-
z
H
5
0
1
0
5
0
0
1
0
0
5
In-Car Response w/ Q-Tune
™
Enclosure Response
B
d
6
0
6
-
2
1
-
8
1
-
4
2
-
0
3
-
6
3
-
z
H
5
0
1
0
5
0
0
1
0
0
5
In-Car Response w/ Q-Tune
™
Enclosure Response
SureSet
™
Fuse Configurations
G3124 / G3104
G31244 / G31044
G3 Included Hardware
Model:
G31244
G3124
G31044
G3104
7.5-Amp Fuse* :
2
2
2
2
Wood Screw M4 x 38mm:
8
8
8
8
2.5mm Hex Key:
1
1
1
1
*Installed on Subwoofer
Note: The SureSet
™
feature utilizes standard automotive ATC fuses to
select between series or parallel voice-coil operation (DVC only). The
fuses also provide voice-coil protection under transient conditions such
as accidental momentary overdrive. The fuses will not protect against
voice-coil failure resulting from long term high power abuse.
2-ohm operation
8-ohm operation
4-ohm
