IIMPORTANT: The following
pictorials are located on your unit
or on literature supplied with the
product. Before you operate the
unit, learn and understand the
purpose for each pictorial.
Saf ety Warning Pictorials
1
WARN ING
2
IMPORTANT: Read owner's
manual before operating this
machine.
3
WARNING: Thrown objects.
keep bystanders away. Read
user instructions before
operating this machine.
4
WARNING: Do not use this ma-
chine on slopes greater than 10
degrees.
5
DANGER: Keep people,
especially children away from
unit.
6
DANGER: No step.
7
DANGER: Keep feet and hands
away from rotating blade.
8
DANGER: Disconnect spark
plug wire before servicing unit.
9
WARNING: Hot surface.
10 WARNING: Use caution when
connecting or disconnecting
accessories .
11 WARNING: Crushed fingers.
12 IMPORTANT: Follow instruc-
tions in owner’s manual to level
the deck.
13 WARNING: Stay clear of
mower blade as long as engine
is running.
Operation Pictorials
1
Engine Start
2
Lights
3
Engine Stop
4
Engine Run
5
Engine Run
6
Brake
7
Parking Brake
8
Clutch
9
Slow
10 Fast
11 Choke
12 Oil
13 Blade Rotation Control
14 Raise
15 Fuel
