Double Revolving Oven Replacement Parts
12
Figure 3. Cooling Fan
Table 3. Cooling Fan Parts
ITEM # PART # QTY DESCRIPTION
1 FB95126202 1 FAN PLENUM, DR
2 FN0014 1 FAN, 230V NMB 3115FS23WB30
3 FA95129702 1 AIR DEFLECTOR, DR
4 SCR315 4 SCREW, 6-32 X 2 RD HD SLTD
5 WSH089 10 WASHER, #6 INT LOCK ZINC PLATED
6 NUT048 6 NUT, 6-32 HEX ZINC PLTD
7 F0243 3 TERMINAL, 1/4" QUICK CONNECT
