➊
➌
➋
➎
➏
➍
➏
GB
The electronic operating manual can be found at
www.zueco.com
Guarantee – notes
Guarantee: Independent of warranties for defects, Züco
grants a 5-year gurantee in the case of normal use at 8 hours
a day. If used for longer periods of time, the Guarantee period
shortens accordingly. Product parts which are subject to
general wear and defects caused by improper use, improper
treatment, extreme climatic conditions, improper tampering,
materials placed on the chair or deviations from the standard
designs as requested by the customer are exempt from the
guarantee.
Castors: hard castors are fitted as standard for soft floors.
Soft castors (grey tread) are required for hard floors. The user
may change the castors himself/herself if necessary.
Maintenance: the chair is maintenance-free if used in the
correct manner. We recommend that you occasionally adjust
the seat height.
Cleaning: please do not use any aggressive cleaners or che-
mical cleaning agents to clean the surfaces of the chair and
the upholstery.
Gas lifts: only trained specialists may work on the gas pres-
sure lifts. There is a considerable risk of injury if improper work
is carried out.
Cuboflex meets technical and occupational medical
requirements and is in conformity with Din standard
1335/1­3. the safety test Mark was issued by tÜV
rheinland.
we reserve the right to make technical changes.
➊ seat­depth adjustment using
sliding seat:
To increase the seat depth: Put your
weight on the seat, pull out the left-
hand lever at the front of the seat
and push the seat forwards.
To reduce the seat depth: Take your
weight off the seat, pull out the left-
hand lever at the front and the seat
will move back automatically.
➋ infinite seat­height
adjustment:
To raise the seat: Take your weight
off the seat, pull the right-hand lever
at the front of the seat upwards and
the seat will rise.
To lower the seat: Put your weight
on the seat, pull the right-hand lever
at the front upwards and the seat
will lower.
➌ Back rest tension
adjustment:
You can alter the backrest tension to
suit your own body weight. Turning
the wheel (at the front, bottom right)
clockwise (+) increases the back rest
tension. Turning the wheel anticlock-
wise (-) reduces the back rest tensi-
on. The back rest tension can be set
between 45 and 120 kg.
➍ synchronised mechanism:
With the lever at the front left under
the seat, you can choose between
the synchronised setting and setting
the seat and backrest in any desired
position. If the lever is in the horizon-
tal position or pushed downwards
and you put your weight against
the backrest, the Cuboflex will syn-
chronously follow your movements.
Pulling it into the uppermost posi-
tion will lock the Cuboflex in your
chosen position. Pushing the lever
into the bottom position and putting
your weight against the backrest at
the same time will activate the for-
ward seat tilt. To deactivate the seat
tilt again, put your weight against
the backrest and move the lever into
the middle position.
➎ Height­adjustable backrest:
The backrest height can be adju-
sted using the Easy-Touch-System.
To do so, hold the backrest at the
sides and adjust it to the desired
height by pushing gently upwards.
The backrest has an 8 cm adjust-
ment range. When you are sitting
up straight, the curved part of the
backrest cushion should ideally be in
your lumbar region.
➏ Multifunctional arm rests
(height/width):
You can adjust the height (maximum
range of adjustment 110 mm) by
pressing the button under the arm-
rest. You can also adjust the width
between the arm rests to create a
larger seat area by releasing the
black lever under the seat on each
arm rest.
