Specifications – Wood’s Powr-Grip MT1TL6FAIR User Manual

Page 3

Rev 6.0/12-12

MT1-AIR: #35080

SPECIFICATIONS

Model Number:

MT1TL6FAIR

Description:

Designed for use with a crane or other hoisting equipment, the
MT1TL6FAIR lifter employs vacuum to hold a load for lifting, and

it provides manual 90° tilt movement for load manipulation.

Power Source:

Compressed air, 80-150 psi [550-1035 kPa] line pressure, 2 SCFM

[57 liters/minute] @ 80 psi [550 kPa]

Vacuum Pad / Pad Spread: One 6" [15 cm] nominal diameter, concave (Model TL6F),

standard rubber, with #60 filter screen

Maximum Load Capacity: 50 lbs [25 kg] rated at 16" Hg [-54 kPa] on clean, smooth,

nonporous flat surfaces

Lifter Weight:

3.25 lbs [1.47 kg]

Vacuum System Weight:

2.15 lbs [0.96 kg]

Tilt Capability:

Manual, 90°

Vacuum Pump:

Venturi type, 1 SCFM [28 liters/minute] nominal vacuum flow @

80 psi [550 kPa]

Vacuum Reserve:

Vacuum reserve system helps prevent immediate vacuum loss in

case of power failure.

Vacuum Gauge:

Dial gauge indicates current vacuum level in positive inches of Hg

and negative kPa.

Operating Elevation:

Maximum = 13,000 feet [3962 meters]

Operating Temperatures: 0° to 120° F [-18° to 49° C]
Service Life:

This lifter is designed to have a service life of at least 20,000

lifting cycles, when used and maintained as intended. Vacuum

pads, filter elements and other wear-out items are excluded (see
MAINTENANCE and REPLACEMENT PARTS LIST for more
information). For the D

ISPOSAL OF THE

IFTER

after its service life,

see INTENDED USE.

ASME Standard BTH-1:

Design Category "B", Service Class "0" (see www.powrgrip.com

for more information)

!!-CE-!! Note: This symbol appears in the

INSTRUCTIONS

manual only when requirements of a CE Standard are

different

from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory

in geographical areas where CE Standards apply, but may be optional in other locations.

Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V

ACUUM

AINTENANCE

: Friction Coefficient for

additional information.
