Wood’s Powr-Grip EO8RC1 - Manual (Page 3)

Rev 0.2/3-12 1 EO8RC1 - MRTALP: #35231
INSTALLATION
Tools
1) 7/16" wrench
2) Philips head screwdriver
3) Needle-nose pliers
4) Wire stripper/cutter
Disassembly
Note: See the Operating Features in the MRTALP-DC lifter's instruction manual to identify any
features not clearly shown in the FIGURES to follow.
1) Place the pad frame with the vacuum pads (pad covers on) facing downward on a clean, flat
surface.
2) Disconnect the electrical connectors uniting the battery to vacuum generating system.
3) If the lifter was
manufactured before 09/01/2011 , remove the vacuum switch cover and
retain the 5 screws for use in Assembly, to follow.
Assembly
1) Mount the radio receiver assembly from the back side of the pad frame using the fasteners
supplied (see FIGURE 1).
2) Connect the electrical connectors uniting the radio receiver and control enclosure (see
FIGURE 1).
3) Connect the electrical connector on the strobe light to the corresponding connector on the
lifter (see FIGURES for strobe light position).
Alternatively, if the lifter was
manufactured before 09/01/2011 , insert the cotterless hitch pin
into the hole in the pad frame as shown in FIGURE 2. Cut the electrical connector off the
strobe light assembly. Then run the strobe light wires through the tube as shown (see
FIGURE 2). Strip the wire ends and connect the strobe light according to the wiring diagram
in the MRTALP-DC lifter's instruction manual.
4) Mount the strobe light assembly using the fasteners supplied (see FIGURE 1).
5) Reinstall the vacuum switch cover with the screws that were retained in Disassembly.
6) Connect the electrical connectors uniting the battery to the vacuum generating system. The
lifter is now operational.
7) Perform Operational and Load Tests for the lifter as directed in MAINTENANCE: T
ESTING
S
CHEDULE
of the MRTALP-DC lifter's instruction manual. Also see the lifter's instruction manual
for SPECIFICATIONS and OPERATION instructions.
