13
Express® Lavatory System - MG Series with Battery Infrared Control
Installation Instructions MG-2/BIR3
Bradley Corporation • 215-1510 Rev. D; ECN 07-815 8/23/07
Assembly of Components
SPRAYHEAD BODY
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
BOWL
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (RIGHT)
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (LEFT)
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
SPRAYHEAD
MOUNTING BOLTS (3)
STAINLESS STEEL
ACCESS PANEL
186-1263.
Figure 8
Other replacement parts
