Connections, Top panel removal / installation – Boston Acoustics Boston GT GT-5750 User Manual
Page 4
GT-5750
1
3
2
2
2
4
8
7
6
5
10
9
C
o
n
n
e
c
ti
o
n
s
4
Connections
Front Channel RCA Input
Remote Turn-On (female spade connector supplied)
Rear Channel RCA Input
Subwoofer Channel RCA Input
Remote Gain Port (refer to GT-RSL manual for installation instruction)
Front Left & Right Speaker Outputs (12-gauge accepted)
Rear Left & Right Speaker Outputs (12-gauge accepted)
Subwoofer Mono Speaker Outputs (12-gauge accepted)
12v Power Input (4-gauge accepted)
Ground Wire Inputs (4-gauge accepted)
Top Panel Removal / Installation
The cover panel is secured with two (2) 3mm screws. Once unscrewed, pull panel forward,
once clear of the corners of the end panels, it will lift off. Reverse to reinstall.
