Schematic wiring diagram cwtfa no warmer, 230 volts ac 2 wire single phase, Page 32 – Bunn C User Manual
Page 32
Page 32
10841 042401
READY INDICATOR
BLK
BLU
SW. & THERMOSTAT
P3
BLK
P1, P2, & P3 ARE PINS OF A
POLARIZED THREE-PIN
CONNECTOR.
WHI
BLK
SOL
BLU
BLU
WHI
BREW
TIMER
P1
P2
WHI
OPTIONAL AUTOMATIC BREW CIRCUIT
SCHEMATIC WIRING DIAGRAM
CWTFA NO WARMER
RED
BLK
WHI/RED
WHI/RED
TANK HEATER
L1
GRN
BLK
RED
L2
HEATER
SWITCH
BLK
BLK
BLU
ON/OFF
SWITCH
WHI/RED
"KEEP WARM" HEATER
WHI
THERMAL
FUSE
THERMAL
FUSE
BLK
BLK
LIMIT
THERMOSTAT
230 VOLTS AC
2 WIRE
SINGLE PHASE
WHI
OPTIONAL FRESH LIGHT SYSTEM
BLK
4
3
2
1
PNK
GRY
L.E.D.
INDICATOR
TIMER
WHI
WHI/ORA
START SWITCH
RED
RED
