Center Focus
Diopter Ring
Prism Housing
Objective
Lenses
Center Hinge
Tripod Adapter
Socket
Neckstrap
Attachment
Point
The Vipers are rugged roof prism binoculars. The
waterproof, dust proof, and internally fogproof design
features an internal focusing mechanism, o-rings at all
open points, and argon gas purging.
Rugged Design
Adjustable
Eyecup
The Viper binocular comes with two tethered
objective lens covers and a one-piece rainguard
that covers the eyepieces. For convenience, the
rainguard can be attached to the neckstrap where
it is within easy reach. Simply slip the neckstrap
through the attachment point on the rainguard
before connecting the neckstrap to the binocular.
The Lens Covers
The Viper carry case provides protection for the
binocular when not in use.
For an easy carry in the
field, clip the woven nylon
neckstrap onto the case.
The Case
Preparing the Viper for Use
