2 3
Magnification
Adjustment Ring
Windage
Adjustment Knob
Reticle Focus
Illumination Knob
and Battery Cover
Objective Lens
RZR Zero Stop and Elevation
Adjustment Knob
Side Parallax Focus
MagView
Radius Bar
(3) Turret Cap
Retaining Screws
Zero Reference
Line
Razor 5–20x50 Riflescope Specifications
Waterproof Yes
Fogproof Argon gas purging
Length 15.8 inches (402 mm)
Mounting Length 6.9 inches (175 mm)
Weight 35.2 ounces (1000 g)
Eye Relief 3.9 inches (100 mm)
Field of View 5x: 22.0 feet /100 yards (4.2°)
20x: 5.76 feet /100 yards (1.1°)
Recoil Tested Rated for .50 BMG
Battery CR2032
Accessories included with the Razor HD
Flip cap lens cover with killFLASH ® ARD
4-inch sunshade
35mm bubble level
2mm hex wrench
The Vortex Razor HD 5-20x50 Riflescope
Reticle Style EBR 1 - MOA EBR 2 - MRAD
Windage 125 MOA 36 mrads
Elevation 125 MOA 36 mrads
Per Rotation 15 MOA 5 mrads
Per Click 1/4 MOA 1/10 mrads
Adjustment Specifications
4.0” (102mm) 6.9” (175mm) 4.9” (125mm) 4.0” (102mm)
15.8” (402mm)
1.7”
(43mm)
2.3”
(58mm)
(Eyepiece) (Sunshade)
2.5”
(64mm)
2.9”
(74mm)
