Solo, Solo r/ t – Vortex Optics SOLO TACTICAL R/T 8X36 MONOCULAR WITH RETICLE FOCUS User Manual
Page 3
solo
tactical monocular
solo
R/ T
5
4
B
ASIC
O
PERATION
Adjusting the Focus
Designed for quick single-
handed operation, simply
place the thumb and
forefinger on the focus wheel
and turn to move lens forward
or backward.
Adjusting the Eyecup
The heavy duty flared rubber
eyecup on the Solo Tactical R/T
monocular folds up and down for
optimal viewing with or without
eyeglasses.
• Flared eyecup blocks stray light when fully extended.
• Eyecup folds down for viewing with eyeglasses.
Rotate
to focus
reticle
Rotate to
focus image
• Top focus wheel adjusts the reticle.
• Bottom focus wheel adjusts the image.
Adjustable flared eyecup
Attaching the Lanyard
Attach lanyard in a few simple steps:
1. Detach clip from the lanyard.
2. Push the loop end through the
attachment point on the monocular.
3. Pull the clip through the loop and
cinch tight.
4. Re-attach the clip to lanyard.
