Vortex Optics DIAMONDBACK 20-60X80 SPOTTING SCOPE User Manual
Page 2
spotting scopes
spotting scopes
Twist-up Eyecup
Focus Dial
Retractable
Sunshade
Objective Lens
Ocular Lens
Magnification
Adjustment Ring
Tripod Mount Collar
Tripod Mount Foot
The Diamondback
®
spotting scope delivers a high level of performance in a trim,
lightweight package—the ideal combination of quality optics and portability.
T
he
D
iamonDback
®
S
poTTing
S
cope
Comes with zoom eyepiece
and custom-fitted case.
- 3 -
- 2 -
