HS LR
RIFLESCO PE
The Vortex ® Viper ® HS LR ™ Riflescopes
Dual Use: Shooting Tactical / Hunting
US Patent 7,937,879
The Vortex ® Viper ® HS LR ™ rifl escopes are intended for dedicated
long range hunters. Using a specially designed uncapped, rapid travel
elevation turret with our CRS zero stop, this rifl escope accommodates
the unique needs of hunters who prefer to “dial in” elevation adjustments
for long range shots.
The Viper HS LR series rifl escopes also provide an ideal platform for
the optional Vortex TMT custom turret caps. Visit our website,
www.vortexoptics.com, for more information on the TMT caps.
Objective
Lens
Fast Focus
Eyepiece
MagView Elevation
Adjustment Knob
Side Focus Knob
Windage
Adjustment Knob
Magnification
Adjustment Ring
Reticle Focus
