RIFLESCOPE

Indexing Adjustment Dials with Zero Reset

Crossfire II riflescopes feature windage/elevation dials that allow you to
re-index the zero indicator after sight-in without disturbing your settings.
Though not required to do, this process will allow you to quickly return to
your original zero if temporary corrections are dialed in the field. Reset the
windage and elevation dials in this way:

1. Remove the outer
cap. While firmly
holding the dial, loosen
and remove center
screw.

2. Lift dial off of scope.
Orient dial to reposition
the zero mark on the
index line.

3. Install dial and
reinstall and tighten
center screw while
firmly holding the dial.

AinTenAnCe

Cleaning

The fully waterproof and fogproof Vortex Crossfire II riflescope requires
very little routine maintenance other than periodically cleaning the
exterior lenses. The exterior of the scope may be cleaned by wiping with a
soft, dry cloth.

When cleaning the lenses, be sure to use products, such as the Vortex Fog
Free cleaning products or Lens Pen, that are specifically designed for use
on coated optical lenses.

• Be sure to blow away any dust or grit on the lenses prior to wiping the
surfaces.

• Using your breath, or a very small amount of water or pure alcohol,
can help remove stubborn things like dried water spots.

Lubrication

All components of the Vortex Crossfire II riflescopes are permanently
lubricated, so no additional lubricant should be applied.

Note: Other than to remove the turret caps, do not attempt to disassemble
any components of the riflescope. Disassembling of riflescope may void
warranty.

Storage

If possible, avoid exposing your Vortex riflescope to direct sunlight or any
very hot location for long periods of time.
