Vigo VG0902K - Manual (Page 3)

THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"
MODEL VG09002K
BACK VIEW
FLOOR
ADJUSTABLE
12 1/2"
16"
17 1/2"
5 5/8"
4 3/4"
3
ROUGHING-IN
Open space for
Rough-In Plumbing
Should be at the same height
as the center of the 2"x6"
Backing Material
NOTE: Vigo reserves the right to change or alter their products or warranty. Vigo recommends using the physical attributes and dimensions
of the actual product and not the installation instructions when preparing the site for your roughing-in.
