PROCON
®
CANNED MOTOR PUMP 7000
Specification Sheet
Motor Voltage (Frequency) 230/220 (50-60 Hz / 50-60 Hz) Motor Voltage (Frequency) 230/220 (50-60 Hz / 50-60 Hz)
Capacitor 20 μf
Phase Single
Speed 2880 @ 50 Hz
Power .5 HP Output Equivalent (375 Watt)
Motor Insulation Class B; IPX4
Flow Range @ 50 Hz 46 to 440 lph
Elastomers Nitrile, EP,
Fluorocarbon, Neoprene
Maximum Inlet Water Temperature * 30°C
Maximum Operating Pressure 13.8 bar
Maximum Relief Valve Pressure 17.2 bar
Maximum Inlet Pressure 6.9 bar
Burst Pressure 68.9 bar
Maximum Dry Suction Lift for Priming with Relief Valve ** 2.00 m
Maximum Ambient Air Temperature 42°C
For applications above 42°C consult the factory
Minimum Ambient Air Temperature 4°C
For applications below 4°C consult the factory
Minimum Inlet Water Temperature 0°C Non frozen
For applications below 0°C consult the factory
Porting Configurations 3/8” NPT, G3/8-19 BSPP
Wiring Configuration - Standard
Male Plug Part # AMP 1-480702-0
Socket Part # AMP 350551-1
Female counterpart
Cap Part # AMP 1-480703-0
Pin Part # AMP 350552-1
Wiring Configuration - Alternate
* Temperatures above 30°C have not been evaluated for ETL compliance ** Not recommended for normal operation
PROCON ® Products
Acragar Road, Mountmellick, Co. Laois Telephone: 011-353 (502)24350 Email: [email protected]
Republic of Ireland Fax: 011-353 (502) 24744 Telex: (852) 60019
“QUALITY PRODUCTS – DELIVERED ON TIME”
230 VOLT
GREEN / YELLOW (GROUND)
BLUE (NEUTRAL)
BROWN
BROWN
BLUE (NEUTRAL)
220/230 VOLT
