Technical Specifications:
Part No.
RMT-103
Input voltage range
18-75 V
Under voltage lockout
17 V
Input filter
PI type
Voltage accuracy
+/- 1% max
Short circuit protection
Continuous
Line regulation
+/- 0.2 max
Load regulation
+/- 0.2 max
Over voltage protection trip range
115-140%
Current limit
110-160% nominal input
Efficiency
Greater than 84%
Switching frequency
300 KHz typical
Operation case temperature
-40°C to 100°C
Storage temperature
-55°C to +105°C
Thermal shutdown, case temperature
+100°C typical
Case material
Aluminum
2000 Technology Parkway, Newark, New York | 315-332-7100 | Fax: 315-331-7800
©2010 Ultralife Corporation • www.ultralifecorp.com • all specifications subject to change without notice
The information contained herein is for reference only and does not constitute a warranty of performance •
11 May 2010 Rev A
Expansion Shelf
RMT-103
