Page 11

CH0003 Operation Manual

Newark, New York | 315-332-7100 | Fax: 315-331-7800

The information contained herein is for reference only and does not constitute a warrant of performance •

30 SEP 10 UBI-5156 Rev: G

Page 11 of 16

CAUTION: Prior to charging any rechargeable battery, verify the type of battery to
be charged. The CH0003 consists of six charge modules and a Control/Filter
Board. The CH0003 will safely and completely recharge UBI-2590, BB-2590,
UBBL09 Li-ION, BB-390/U, BB-590/U, and UBBL02 batteries.

Battery

Description

Manufacturer

NSN

Charge Cycle

BB-390/U

Nickel Metal Hydride 12/24VDC

Bren-Tronics

6140-01-490-4317

4 hours

MAI-390

Nickel Metal Hydride 12/24VDC

Mathews &
Associates

hours

BB-590/U

NiCad 12/24 VDC

Various

2.5 hours

MAI-590

NiCad 12/24 VDC

Mathews &
Associates

2.5

hours

UBI-2590 Lithium-ion

Ultralife

hours

BB-2590/U Lithium-ion

Bren-Tronics

6140-01-490-4316 6

hours

UBBL09 Lithium-ion

Ultralife

6 hours

UBBL02 UBI-2590

Lithium-ion

Ultralife

6140-01-553-3527

6 hours

NOTE: If a battery type is encountered which is not listed in the table above, please
contact Ultralife Corp at the address or E-mail provided throughout this document.

3.4 Battery Discharge

The CH0003 allows the operator to discharge batteries. During the discharge function the top heat
sink surface of the charger will become warm. This is normal operation. During discharge operation
locate the CH0003 in a well-ventilated area and ensure no flammable materials are near the unit.

3.5 Start-up

The CH0003 automatically determines the battery type connected. The operator can either plug the
CH0003 into a power source or attach the batteries to the unit first. Once the batteries are attached
and power applied to the unit, the batteries automatically start charging.

3.6

LED Indicators

There are four groups of LEDs indicating the status of the charger. Refer to Figures 3 and 4 on the
next page and the paragraphs that follow.
