19 ae owner’s manual parts list ae – Billy Goat AE400H User Manual
Page 19
Part No 360251
Form No F050107A
19
AE Owner’s Manual
PARTS LIST AE
ITEM
AE400H
AE450
NO.
Part No.
Part No.
1
FRAME ASSEMBLY
360273
1
360273
1
4
BEARING 3/4" PILLOW BLOCK
350133
4
350133
4
5
SCREWCAP 3/8-16 x 1 1/2
8041052
12
8041052
12
6
FRONT AXLE 3/4"
360259
1
360259
1
7
KEY SQUARE 3/16 x 3/16 x 1.25
9201080
3
9201080
3
8
WHEEL 10.5" SEMI PN. W3/4" KEYED HUB
360157
2
360157
2
9
FENDER WASHER 5/16"
8172020
3
8172020
3
10
WASHER LOCK 5/16 TWISTED TOOTH
430298
2
430298
2
11
SCREWCAP 5/16-18 x 1"
8041028
2
8041028
2
12
GUARD DIFFERENTIAL AE
360248
1
360248
1
13
SCREW SELF TAP 1/4 x 1/2"
8122080
2
8122080
2
14
JACKSHAFT AERATOR
360253
1
360253
1
15
BEARING 1" PILLOW BLOCK
810700
2
810700
2
16
NUT LOCK 3/8-16
8160003
16
8160003
16
17
COILED PIN 1/4" - 2.25" LONG
360257
5
360257
5
18
PULLEY 8" x 1" BORE W/ HOLE
360237
1
360237
1
19
SPOCKET 16Tx 1" BORE
360260
2
360260
2
20
BELT 4L x 43" POWER RATED
360120
1
360120
1
21
CHAIN #40 x 94 PITCH O-RING (WHEEL)
360115
1
360115
1
22
CHAIN #40 x 76 PITCH O-RING (TINE)
360114
1
360114
1
23
PULLEY IDLER 4.5"
500270
1
500270
1
24
ARM IDLER WA
510199
1
510199
1
25
BRACKET MOUNT IDLER
360121
1
360121
1
26
BELT FINGER FRONT AE
360219
1
360219
1
27
28
BOLT SHOULDER 1/2 x 1
500114
1
500114
1
29
SPROCKET IDLER 17T x 5/8" BORE
360116
2
360116
2
30
SPACER SPROCKET IDLER 2.5"
360123
1
360123
1
31
SCREW CAP 1/2 - 13 x 4
8041106
1
8041106
1
32
SPACER SPROCKET IDLER 1.175"
360124
1
360124
1
33
SCREW CAP 1/2 - 13 x 3"
8041102
1
8041102
1
43
WASHER FLAT 3/8 SAE
8172009
12
8172009
12
DESCRIPTION
QTY
QTY
ITEM
AE400H
AE450
NO.
Part No.
Part No.
44
SCREWCAP 3/8 -16 x1
8041050
2
8041050
2
49
FLAT WASHER 1/2"
8171006
4
8171006
4
50
NUT LOCK 5/16-18
8160002
55
8160002
55
55
CABLE CLUTCH ASSY
360119
1
360119
1
59
SPACER TINE SPROCKET END
360108
1
360108
1
60
PULLEY ENGINE
360117
1
360117
1
61
SPROCKET 42 T
360106
1
360106
1
62
SPACER - TINE SPROCKET 1.468
360272
3
360272
3
63
SCREW CAP 5/16-18 x 2.50"
8041034
3
8041034
3
64
TINE PLATE
360101
8
360101
8
65
TINE
360100
24
360100
24
66
SPACER - NUT RIGHT END
360266
1
360266
1
67
SPACER - BETWEEN TINE ASSEMBLIES
360265
3
360265
3
69
HEAVY WASHER TINE ASSY
830113
1
830113
1
70
WASHER LOCK 7/8" INTERNAL
350154
1
350154
1
71
NUT JAM 7/8 -14 (Torque 100 ft.lbs)
350155
1
350155
1
72
CARRIAGE BOLT 5/16-18X1.75
8024043
48
8024043
48
73
SHAFT TINE DRIVE
360102
1
360102
1
74
SCREW CAP 5/16 - 18 x 1.5"
8041030
4
8041030
4
75
WASHER FLAT CUT 5/16
8171003
9 OR 10
8171003
9 OR 10
77
LABEL HOT ENGINE
400268
1
400268
1
78
LABEL DANGER GUARD
900327
2
900327
2
80
NUT LOCK 1/2 -13 THIN
8161044
2
8161044
2
81
SPACER BEARING/SPROCKET 0.375 THK
360109
1
360109
1
90
ENGINE
360278
1
360127
1
94
LOCKNUT 3/8" - 16 THIN HGT
8161042
1
8161042
1
106
WASHER 1.062" ID X 1.75 OD
8172021
4 OR 5
8172021
4 OR 5
108
CHAIN MASTER LINK
360205
2
360205
2
115
SPROCKET 35 TOOTH
360252
1
360252
1
119
SPACER - TINE PLATES
360105
4
360105
4
120
TINE ASSY (INCLUDES 50,64,65,72,&119)
360197
1
360197
1
121
RUBBER PAD 1/8" TK X 1/2" W
350310
1
350310
1
DESCRIPTION
QTY
QTY
