Introduction
TerraWave’s 9’ Site Survey Extension Pole is used during a professional site survey to assist system
engineers with a convenient way to raise an access point (AP) and antenna to an extended height without the
need and use of a ladder.
The maximum height of the site survey extension pole is 9 Feet.
Before assembling this product, read these instructions carefully. Failure to follow these instructions could lead
to damage to the product or cause hazardous conditions.
Included Components
TerraWave Part Number: TWS-SSROD-BUND
TESSCO SKU: 362747
Kit Includes:
- Site Survey Extension Pole
- Universal Mounting Bracket
- Traveling Case with Wheels
TerraWave Part Number: TWS-SSROD-BKT
TESSCO SKU: 392506
Kit Includes:
- Site Survey Extension Pole
- Universal Mounting Bracket
Technical Specifications and Features
Site Survey Extension Pole
- Maximum Height Extended: 9’
- Height Contracted: 3.5’
- Footprint with Legs Extended: 40” x 40 “
- Weight: 8.5 lbs
Universal Mounting Bracket
- Length with Wings Extended: 20”
- Width with Wings Extended: 9”
- Wing Dimensions: 8” x 5”
- Weight: 1.5 lbs
Traveling Carrying Case with Wheels
- Material: Durable black canvas with Vinyl trim
- Handling: Equipped with strong top handle and comfortable, padded carrying strap for easy portability.
- Case Dimensions: 49” x 9”
- Wheel Diameter: 4”
