TaoTronics TT-GL14 User Manual
Tt-gl14, Specification, Characteristics

TT-GL14
Prouct name:80*3W LED Grow Light
LED Quantity:80pcs
LED Type:3W
Size:400*212*60mm
Certificate:CE ROHS
Specification
Size
400*212*60mm
Model
TT-GL14
Input Voltage
AC85~264V
Output current
600mA
Output Voltage
50-100V
LED Quantity
80pcs
Lifespan
50000h
LED Type
3W
Working Environment
45%~90%RH -20~40℃
Color
Red/Blue
Working Frequency
50~60Hz
Lumens
3200lm
Lux
346/2m 163/3m
Lighting Area
51㎡/2m 79㎡/3m
Size(Inner box)
515x255x115mm/1PCS
G.W.(Inner box)
4kg
Size(Outer box)
530x520*130mm/4PCS
G.W.(Outer box)
17.1kg
Characteristics
1.The lifespan is over 50000 hours,low maintenance costs.
2.Energy conservation, saving over 80% energy than the traditional HPS.
3.High light efficiency, 90% of the light will be absorbed by the plants, while just 8%-10% to the HPS.
4.Build-in cooling system,could solve the heat dissipation excellently.
5.Built-in power supply, CE approved, No setup required, just simpler and safer plugs directly into AC85V-264V, no reflector
& ballast needed.
6.Ideal for all phases of plant growth, and works well with any indoor garden, hydroponics or soil based.
7.The lighting area and the height are changeable according to different plants and environments, the same as the
parameter.
8.Environment-friendly, no mercury and other harmful heavy metal.
9.Use high quality LED trips as lighting resource.
Application
Ideal for all phases of plant growth, and works well with any indoor garden, hydroponics or soil based. Can be used in green
house, flower exhibition, bonsai, garden, green house, sowing,breeding, farm and so on.
Attention
1.Do not use the lights in dripping water or anywhere where they will get wet, water and electricity can be a dangerous
mixture.
2.The working environment for LED aquarium light is -20~40℃,45%RH~90%RH.
3.To protect the light, Pls cut off the power when there is a lightning strike.
4.Don’t touch or move when the light working.
