Specifications
d
imenSionS
:
Figure 1: dimensions of GcI60.
S
peciFicationS
:
Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) & Wheat/Barley - 53,000BTU (15.5KW•hr).
Table 1: GCI60 Specifications.
Description Fuel type
Residential Pellet Heater 6mm (¼”) dia. Pellets - wood, corn, wheat, & barley*
Voltage Current Max Power
110 - 120 V 4.2 Amps 504 Watts
Frequency Hopper Capacity Consumption on Low
60 Hz up to 50 lb (22.7 Kg) 1.5 lb/hr (0.68 Kg/hr)*
Testing Standard Weight (with full hopper) Consumption on High
ASTM 1509-04 370 lb (167.8 Kg) 6.5 lb/hr (2.95 Kg/hr)*
*Note: Consumption will vary with the type and quality of pellets / fuel used.
33 9⁄16
43 3⁄16
41 7⁄8
16 3⁄8
24 ¾
26 7⁄8
22 15⁄16
11 ¾
12 ¾
Hampton GCI60 Cast Pellet Insert Owner’s Manual 7
