Switronix PB70C300 - Manual

Powerbase 70-C300
Instruction Manual
Switronix, Inc.
87 Garden St Tel: 1-800-613-7948, 516-750-9675
Westbury, NY 11590 Fax: 516-594-1414
Website: http://www.switronix.com
1. Using conversion box GP-DV-C300 the Powerbase 70
can supply 7.2V for Canon cameras with a the appropriate
dc pin connection. It can also supply 12V for accessories
through the conversion box PT socket.
2. Included conversion box/cable applicable camera
models:
-Canon C100/300/500 Camcorders
Specifications
Rated Voltage: 14.8V
Rated Capacity: 70Wh
Charge Time: 3~5 hrs
Dimensions: 6.25in x 3.4in x 2in
Weight: 1.5lbs
Four step LED power indication
1. Can be used as normal V type brick battery
2. Built-in PT port can supply power for accessories
or charging.
3. Quick release plate can be used to install wireless
reciever, hard drive or other equiptment or to connect
two batteries.
4. Both sides have a 1/4” 20 insert for installing other
equipment
