Location of Parts
Typical Top Surface
NOTES:
1. Model C301 has sink on right and cooktop on left.
2. All models include a storage compartment with shelf and are shipped fully assembled, including fau-
cet. Each model comes with a refrigerator that fits precisely into the slot in the assembly that has
been prepared for it.
Operating Your Cooktop
Either burner can be turned on by pushing the control knob down and turning it clockwise or counter-
clockwise to the desired setting. To adjust the setting, turn the knob without pressing down. The burner
is turned off by turning the control knob clockwise or counter-clockwise to "OFF".
OPERATING INDICATORS
When a burner is turned on, the corresponding LED indicator will light up regardless of the setting.
RESIDUAL HEAT INDICATOR
There is a Residual Heat Indicator on the left front corner of the cooktop surface that will light up
when some part of the glass ceramic cooktop is too hot to touch or place articles upon. Do not place
articles other than cookware on the cooking surface while this light is glowing.
5¾” burner
7” burner
Glass cooktop
Draining
grooves
Sink
Drain
Hot water
Cold water
Thermostat
knob
ON indicator
LEDs
Stainless steel top
FRONT
