Chicco Car Seat Adaptor
for Elite/Classic/Summit Double Strollers
The Chicco Car Seat Adaptor for Double Strollers is designed to be used with your Baby Jogger City Mini,
City Micro, City Series, City Classic, City Elite, Summit 360, or Summit XC double stroller and your Chicco
car seat. This car seat adaptor is only compatible with this car seat and these stroller models.
Bar Fasteners
This Kit Includes:
1 Adaptor Bracket
2 U-Shaped Support Bars
2 Bar Fasteners
How to use your car seat adaptor safely
Adaptor Bracket
1 Un-Velcro seat from footplate area so that silver metal frame bars are visible.
2 Unsnap all snaps on seat below folding mechanism of double stroller.
3 Loosen adjustment knobs on double car seat adaptor.
4 Slide adaptor unit onto right side of the stroller frame.
5 Apply center clamp over center metal frame bar.
6 Tighten both adjustment knobs until center clamp is secure onto stroller frame.
7 On the right side of the stroller frame, attach single clamp between the
lowest rivet and the lowest snap on the
stroller frame.
8 Tighten adjustment knob until clamp is
secure onto stroller frame.
9 Pull seat fabric down to re-attach to
stroller frame using Velcro on and
underneath footplate. To do this, thread
the Velcro strap between the frame and
the adaptor bar. Re-attach snap on right
side of stroller frame above single clamp.
13 Screw Bar Fasteners into holes on the top of the U-Shaped Supports.
14 Place your car seat onto the U-Shaped Support Bars. Adjust the U-Shaped
Support Bars to proper length by sliding the U-Shaped Bar in and out, using
the car seat to ensure proper distance. The Adaptor Brackets should line up
with the handle hinge of the car seat.
15 Close compression locks by flipping the red latches down.
16 Secure your car seat onto the stroller using the safety belt on the car Seat
Adaptor Brackets.
10 Open the compression locks on the Car Seat Adaptor Brackets by flipping
the red latches up.
11 Insert U-Shaped Support Bar (labeled HEAD) into the front holes on the
Adaptor Brackets.
12 Insert U-Shaped Support Bar (labeled FOOT) into HEAD Support Bar.
1 To use with 1 child in left stroller seat and
1 child in the car seat, make sure adaptor
brackets are locked into place on right side.
Press red compression lock down to
secure adaptor into place. 2 To use with 1 child in car seat, release red compression
lock. Slide adaptor bar to the center. Press red
compression lock to secure adaptor into place.
1
7 9
2 4 5
6
NOTE: If only the car seat is in use
without second child, the car seat
adaptor must be locked in the
center of the stroller.
U-Shaped
Support Bars
11/12 13 15 16
8575 Magellan Parkway, Suite 1000 • Richmond, VA 23227 • T: 800-241-1848 • F: 804-262-6277 • www.babyjogger.com
The sample product shown on this manual may differ slightly from your production quality Car Seat Adaptor.
However, this will not affect the assembly or functionality of your Baby Jogger product.
NOTE: It is possible that the length of some car seats won’t allow the double car seat adaptor to slide to the center of the frame.
If this occurs, always balance the stroller weight by adding weight to the opposite seat.
