onto the water tap. (If your washing machine is
fitted with an inlet hose with a partial or complete
Aqua-Stop system, the gasket with the filter net is
already fitted).
•
For hot and cold water connections, connect to
the hot and cold faucets as marked at the rear of
the appliance (letters C and H) (C - cold; H - hot)
•
Fix the outlet hose to drain into the sink or the
standpipe (diameter min. 1,6 inch - 4 cm).
•
Standpipe must be installed properly and must
enable occasional cleaning.
•
Fasten the drain hose support with a piece of
string or cable tie led through the hose elbow, to
prevent the hose from slipping to the floor.
The end of drain hose should be placed between
minimum 4 inch (60 cm) and maximum 40 inch
(100 cm) above the floor level.
•
Plug the main power cable to the wall socket.
•
Required voltage and other information are written
on the rating plate above the door opening of the
machine.
The wall socket must be accessible at all
times and must be equipped with a ground
lead (in accordance with the local safety
regulations).
Damaged main power cable may be
replaced only by the manufacturer or
authorized servicer.
Connect to individual branch circuit.
WHEN THE WASHING PROGRAM IS
OVER, SWITCH THE MACHINE OFF BY
DISCONNECTING THE APPLIANCE FROM
THE MAIN SUPPLY.
10
Connect the appliance
to the mains supply
Water outlet connection
