8
 Reversing the Door Swing of the Freezer
This appliance has the capability of the door opening from either the left or the right side.
The unit is delivered to you with the door opening from the left side. Should you desire to
reverse the opening direction, follow the directions below. If you have a problem, call
SUMMIT Customer Service at 1-800-932-4267.
1) Door hinge cap
2) Door hinge screws
3) Upper door hinge
4) Lower door hinge
5) Plug
6) Short leg
7) Door hinge bolts
8) Front leveling leg
9) Hinge plug (door frame)
a) Remove the upper hinge cap (1).
b) Carefully pry out the plug buttons (5).
c) Remove the two Phillips screws (2) that connect the upper hinge (3) on the right side of
the cabinet top.
d) Carefully lift off the door and place it on a padded surface to keep it from being
scratched.
e) Remove the hinge plug (9) and transfer it to the uncovered hole at the right edge. Be
sure to press the button firmly into the hole.
f) Remove the two bolts (7) that hold the lower hinge (4) on the right side.
g) Remove the screw-type leveling front leg (8) and transfer it to the right side, switching it
with the short leg (6).
h) Set the door into its new place making sure the pin enters the bushing at the lower frame
section (hole).
i) Secure the upper hinge (3) previously removed in step (c) on the left side. Make sure the
pin enters the bushing at the upper frame section (hole).
j) Loosely secure the lower door hinge (4) on the left side and do not tighten the bolts until
the door is in the closed position and leveled.
k) Insert the plug buttons (5) into the uncovered holes (right side).
l) Replace the upper hinge cap (1).
 Locking the Freezer
The freezer comes with two keys and a lock at the bottom center of the door. Turn the key a
quarter-turn to the left to lock the door, and a quarter-turn to the right to unlock it. Keep keys
in a secure place.






