4
Technical Information
Model FS407L FS408BL
Color White Black
Capacity 2.8 cu. ft. 2.8 cu. ft.
Electrical Input 115V AC/60Hz 115V AC/60Hz
Rated Current 1.6A 1.6A
Power Input 90W 90W
Refrigerant R134a, 3.0 oz. R134a, 3.0 oz.
Installation Free-standing Free-standing
Unit Weight 64 lbs. 64 lbs.
Unit Dimensions
(W x D x H*) 19
⅞" x 23¼" x
33¼"
19
⅞" x 23¼" x
33¼"
*For models with suffix ADA, height is modified to 32” for use under lower counters
Installation Instructions
Before Using the Freezer
•
Remove the exterior and interior packing.
:
• Check to be sure you have all of the following parts: 4 drawers, 1 handle with screws
and handle seal, and 2 keys.
• Before connecting the unit to the power source, let it stand for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling
during transportation.
•
Remove the drawers and clean them and the interior surfaces of the unit with
lukewarm water using a soft cloth.
Installing the Freezer
• Place the unit on a floor that is strong enough to support the appliance when it is fully
loaded. To level your unit, adjust the leveling legs at the bottom.
:
• Models FS407L and FS408BL are designed to be free-standing only, and should not
be recessed or built in.
• When installing, allow at least 4 inches of space at the back and sides of the unit,
which will allow the proper air circulation to cool the compressor and condenser.
Be
sure that airflow under the appliance is not blocked.
•
Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase
electrical consumption. Extremely cold ambient temperatures may also affect the
unit's performance.
• Avoid locating the unit in moist areas. Too much moisture in the air will cause frost to
form quickly on the evaporator, requiring more frequent defrosting of the freezer.
