1. First, open the front pockets of the carry case and remove all parts and

backdrops (Figure 1). The 50 Watt lights are fully assembled.

2. Remove and set aside the two tripod pieces for later assembly. Close the

front pouch.

3. Release the back side of the case from the velcro fastening. Remove the

pouch with the backdrops.

4. Next, convert the carry case into a tent by unfolding the white

interior sides of the tent and setting upright (Figure 2). Attach
together with the velcro strip in the corner where the two pieces
meet.

You will now have a three-sided tent.

Flip the tent over so that the open side
is on the bottom and the black case
side is on top (Figure 3). Tuck the
case flap between the case and the

tent material.

5. Attach a background to the tent by

using the built-in velcro strip on the
colored background to join with the
velcro on the tent’s interior top back
crease (Figure 4).

6. Setup the lights by pulling down on

the stands and folding out the
extensions (Figure 5). Adjust the

light heads by first loosening the
knob beside them, repositioning and
then re-tightening the knob.

7. Assemble the tripod by first opening and expanding the black,

adjustable base of the stand. Next, unscrew the securing knob of
the silver shaft and feed it through the base and screw it into the
silver shaft and tighten (Figure 6).

SP200 Professional Kit Setup

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6
