Schwank SCH-200 Construction - Manual (Page 3)

SP-MCH2-BX-07A
SCH-200 MANUAL
R.D: Sept 2004
RL: 7
KH
TECHNICAL SPECIFICATIONS
Input (BTU) - 200,000 (0 to 4500 ft above sea level)
Height (inches): 44” Width (inches): 31”
Ignition controls: standing Thermostat: finger
pilot touch
control
Tip-over switch: 35º Gas inlet: ½”
Clearances to: 48” (top) Minimum gas: 6” (NG)
Combustibles 52” (side) Pressure (W.C.) 11” (LP)
No electric power required.
TABLE OF CONTENTS
INFORMATION AND SAFETY LABELS
4
1.0 INSTALLATION REQUIREMENTS
6
1.1 GENERAL INSTRUCTIONS 6
1.2 GAS SUPPLY LINE/GAS PRESSURE 6
1.3 VENTILATION REQUIREMENTS 6
1.4 CLEARANCES TO COMBUSTIBLES 6
1.5 MOUNTING INSTRUCTIONS 7
1.6 LIGHTING/SHUTDOWN INSTRUCTIONS 8
2.0 MAINTENANCE
8
3.0 REPLACEMENT PARTS
10
4.0 LIMITED WARRANTY
12
5.0 SERVICE OR WARRANTY CLAIM
13
