2 B-CONTROL FADER BCF2000 Technical Specifications
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed
or illustrated.
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER, KLARK TEKNIK, MIDAS, BUGERA, AND TURBOSOUND ARE PART OF THE MUSIC GROUP (MUSIC-GROUP.COM).
ALL TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH
OR STATEMENT CONTAINED HEREIN. COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND RESELLERS ARE NOT AGENTS
OF MUSIC GROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED
IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL RIGHTS RESERVED.
© 2013 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands
B-CONTROL FADER BCF2000
Total-Recall USB/MIDI Controller with 8 Motorized Faders
Total-recall, cascadable desktop MIDI controller with analog feel and intuitive user interface
8 ultra-precise, 100-mm, motorized faders for ultimate control of virtual mixers, organ-drawbars (inverse mode) or virtual synths and samplers
4 virtual groups with 8 dual-mode, high-resolution encoders that feature LED rings and an additional push function
16 + 4 illuminated buttons freely assignable to all types of MIDI functions from note on/off, control change and program change to MMC and system exclusive data
All panel elements freely assignable—manually or via user-friendly learn mode
Additional multi-function foot switch and foot controller connectors can be used to address all types of MIDI data
32 user presets each with 4 encoder groups
Configurable MIDI and USB modes for ultra-flexible system integration
1 MIDI In plus 2 MIDI Outs, usable as an additional USB to MIDI interface
Multi-function, 4-digit LED display with real-time parameter indication plus write-in fields for your own labeling
MIDI input with merge function for cascading several control units
Easy connection to any computer/expander, etc. using standard MIDI In/Out connectors
Generic USB MIDI support with Windows XP (or higher) and Mac OS X operating systems
Additional drivers and editor/librarian software available for free download at behringer.com
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specifications
USB Interface
Type Full-speed 12 MBit/sec. USB MIDI class-compliant
MIDI Interface
Type 5-pin DIN connectors IN, OUT A, OUT B / THRU
Control Elements
Controls 8 motorized 100-mm faders 8 infinitely variable
push encoders with LED rings
Keys 20 keys 10 system keys (4x Encoder Group,
4x programming, 2x Preset)
Display
Type 4-digit 7-segment LED display
Switched Inputs
Footswitch 1 x 1/4" TS connector with automatic
polarity detection
Foot pedal 1 x 1/4" TRS connector
Power Supply
Voltage 100 to 240 V~, 50/60 Hz
Power Consumption max. 10 W
Fuse T 1 A H 250 V
Mains Connection Standard IEC receptacle
Dimensions / Weight
Dimensions (H x W x D) approx. 330 x 100 x 300 mm (13 x 3.94 x 11.8")
Weight approx. 2.7 kg (5.9 lbs)
