The Tru-Flo 3-way diverter port ball valve is designed to have the center

port act as the common port and must be open at all times. You can use

the L-port diverter to go from center to left (Fig. A) or to go from center

to right (Fig. B). The T-port divertor can do the same configurations as the

L-port but can also have all three ports opened at once (Fig. C).

E

F

G

C

B

A

Diverter Port

Size

A

B

C

D

E

F

G

ISO5211

Stem

(mm)

Weight

(lbs)

1"

1.13

4.50

2.25

2.23

7.28

3.62

1.12

F04/F05

11

3.5

1½"

1.37

5.50

2.75

2.44

8.66

4.41

1.53

F05/F07

14

6

2"

1.87

6.25

3.13

3.13

8.66

4.76

1.82

F05/F07

14

9.5

3"

2.88

9.00

4.50

4.50

13.78

6.63

2.91

F07/F10

17

29

4"

3.83

9.50

4.75

4.75

13.78

7.22

3.46

F07/F10

17

44

Item

Part

(Qty)

Material

1

Body

CF3M/316L

2

End Caps

(2)

CF3M/316L

3

Seats

(2)

PTFE

4

Ball

SUS 316

5

Stem

SUS 316

6

Gasket

PTFE

7

Stem Seals

(3)

PTFE

8

Gland Ring

(2)

SUS 304

9

O-ring

VITON

10

Belleville Spring

Washer

(2)

SUS 301

11

Lever Nut

(2)

SUS 304

12

Locking Tab

SUS 304

13

Handle

SUS 304

14

Plastic Coating

Vinyl

15

Stop Screw

SUS 304

16

Bolts

SUS 304

17

Bolts Nut

SUS 304

18

Lock Washer

SUS 304

19

Static Device

SUS 316

20

Body Gaskets

(2)

PTFE

5

10

12

16

17

20

7

8

11

19

4

18

2

3

3

20

2

15

8

11

13/14

6

9

1

A

B

C

»
