Billion BiPAC 2071 / 2072 Homeplug AV 200 Ethernet series

Hardware Overview

The LEDs









The Connector

*

Lit when connected to an Ethernet

device.

*

Blinking when data is

transmitted

or received via Ethernet port.

* Lit when the power line

sync is established.

* Blinking when

networking is active.

* Connect your device (e.g.: computer, router,

hub , IP pone, IPTV set-top-box, gaming
consoles…) to a LAN port, using the included
RJ-45 Ethernet cable

* Lit when power is ON

* Blinking when detecting

HomePlug 1.0 device

*Reset Button: Hold
down the reset button
for 1~3 seconds to
reset device to factory
default.

* Power line sync







- 4 -
