Brinkmann 2400 User Manual
Page 28
27
Step 18
Place the porcelain coated heat
tents on lower level of grill body
assembly directly above burners.
Step 19
Place porcelain cast iron cooking
grills on support ribs directly
above porcelain heat tents.
Step 20
Place warming rack in brackets so
that it sits above the cooking grills.
Step 21
Remove igniter cap and insert
battery with positive end of battery
toward igniter cap. Replace igniter
cap and make sure the igniter is
working properly.
Cooking Grills
Porcelain Heat
Tents
Brackets
Igniter Cap
Battery
Warming Rack
