ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR FRYER.
Inspect contents of the box to ensure all parts are included and undamaged.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(Proof of purchase will be required.)
Tools required to assemble your cooker:
• 10mm Open End Wrench (or an Adjustable Wrench)
• Screwdriver
PARTS LIST:
1 Cooker Body
1 Turkey Stand and Hanger
1 Deep Fry Thermometer
1 Cooking Vessel with Lid
1 Heat Shield
1 Hose & Regulator Control Panel
1
2
3
4
5
3 U-Shaped Legs
(Pre-attached Metal Plate with Safety
Warnings.-Do Not Remove this Plate)
1 Burner Assembly
1 Bottom Heat Shield
6
7
8
9
DISH WASHERSAFE 100
150
200 250
300
350
400
50 200
100 150
°F R °C
CAUTION-HOT
Maximum
Oil Fill Line
Do Not Exceed
18 lb. Turkey
1
2
3
4
5
6
7
9
8
