Bag Boy Express 120 User Manual
Express 120
Express 120
Diagram
Description
Part #
1
Upper Handle Frame Tubing (Select Color Code)
P09016-
2
Scorecard Holder
P21190
3
Upper Bag Bracket w/ Velcro Strap
P14392
4
RH Chrome Draglink
P32590
5
Main Frame (Select Color Code)
P11048-
6
LH Chrome Draglink
P31590
7
2 Hole Side rod (Select Color Code)
P08089-
8
3 Hole Side rod LH (Select Color Code)
P08091-
9
3 Hole Side rod RH (Select Color Code)
P08090-
10
Support Cable
P33387
11
Side Wheel Assembly
P39551
12
Knuckle Cover
P17119
13
LH Knuckle
P17120
14
RH Knuckle w/Brake Attached
P17121A
15
Complete Lower Bracket/Strap Assembly
P67091
16
Front Wheel Assembly
P61081A
1-1/2" Upper Bag Strap w/Velcro Attachments
P46020
1-1/2" Black Buckle Strap w/Plastic Clip
P46022
Color Codes: 02 Navy, 08 White, 10 Red,
11 Charcoal
