Buhler Y180 - Manual (Page 2)

RolleRmill model Y85 Y100 Y180
Size 7" x 8" 10" x 10" 18" x 10"
Roll diameter 8" 10" 10"
Grooves per inch 8 (6 corn) 8 (6 corn) 8 (6 corn)
Roll pressure Double leaf spring Double leaf spring Double leaf spring
Capacity (approx.) 50 - 100 bushels/hr 100 - 150 bushels/hr 200 - 300 bushels/hr
Magnet Optional Optional Optional
Drive required (approx.) PTO or 3 - 5 hp electric PTO or 5 - 7.5 hp electric 40 - 60 PTO hp
Discharge auger Not available Not available 7" x 12' hydraulic (optional)
Tires Not available Not available Optional
Stationary stand Optional Optional Optional
Weight 225 lbs 317 lbs 540 lbs
Scrapers Optional Optional Standard
HAmmeRmill model Y60
Working width 6"
Drive Double-V pulley
Motor required (approx.) 5 - 7.5 hp, 3450 rpm motor (not included)
Capacity (approx.) 75 bushels/hr
Hammers 18, C1045 carbon steel
Rows 6
Screen size 6" wide x 14" round
Height 36" (including hopper)
Width 24"
Depth 19"
Weight 145 lbs
Buhler Hammermills
Grinding grain fresh every day means animals get the most nutri-
tional value. A Buhler hammermill does the job quickly and
economically, grinding as much as 75 bushels per hour. An adjust-
able motor mount fits most 5 to 7.5 horsepower electric motors.
The sliding feed gate controls the amount of grain entering the
mill and an optional magnet removes nails and other metal objects
from grain and prevents damage to the hammermill. An optional
discharge hopper makes it easy to move processed grain.
The hammers are made from high quality carbon steel for extra-
long life. They can be reversed for use in four different positions
for even longer wear.
mAximize nutRitionAl vAlue
