10 – ENGLISH – Manual Text Booklet – Orbit Baby Helix Plus Upgrade Kit
⚠
WARNING
⚠
PINCH HAZARD:
◦
Avoid injury from pinching or finger entrapment. Keep children away when inserting the
Helix SmartHub Attachment. Keep your hands clear of moving parts when inserting and
removing the Helix SmartHub Attachment.
FALL HAZARD:
◦
Always check that the Helix SmartHub Attachment is securely locked into the stroller frame
leg connectors before placing your child into stroller or starting to stroll. Pull backwards on
the Helix SmartHub Attachment and check that the red warning triangles on both sides are
NOT visible.
Assembling and attaching the Helix SmartHub Attachment
⃞ Insert the two Helix SmartHub Attachment wheels Ⓡ. You will hear a CLICK when they are locked
in place.
⃞ Grasp the Helix SmartHub Attachment with one hand while holding the stroller frame with your
other hand. Pull on the release lever Ⓝ and guide both tube ends into the stroller frame leg
connectors Ⓣ until they are fully inserted and the red warning triangles have been fully covered by
the stroller frame leg connectors. You will hear a CLICK when the Helix SmartHub Attachment is
locked in place.
⃞ Check that the Helix SmartHub Attachment is fully locked into the stroller frame by letting go of the
release lever and pulling back on the attachment. You should not see the red warning triangles or
be able to remove the attachment.
Attaching the ShadePad
⃞ Undo the hook and loop fasteners on the backside of the ShadePad Ⓐ. Grasp the ShadePad by
its sides and slide it over the handlebar while pulling it wide open, until the bottom of the ShadePad
lines up with the end of the foam grip. Ensure that the clear window faces upward, the flap with
the two snaps faces the handlebar, and the ShadePad is only on the foam of the handlebar.
