20G400
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5547--10 Assemblies include all parts shown in frames. 10/07/2008
10
188 690877 Screw
(Control Bracket)
190 692127 Screw
(Fuel Tank)
192 690083 Adjuster--Rocker Arm
209 694867 Spring--Governor
211 695307 Spring--Governor Idle
219 693578 Gear--Governor
220 691724 Washer
(Governor Gear)
222A 698034 Bracket--Control
227 694864 Lever--Governor
Control
265 691024 Clamp--Casing
267 692577 Screw
(Casing Clamp)
268 691025 Casing--Control Wire
(Cut to Required
Length)
269 691026 Wire--Control
(Cut to Required
Length)
270 691027 Nut
(Control Wire Casing)
271 696697 Lever--Control
271B 698035 Lever--Control
278 792008 Washer
(Governor Control
Lever)
281A 697400 Panel--Control
-------------- Note ----------
698081 Panel--Control
Used on Type No(s).
0222.
287 691693 Screw
(Dipstick Tube)
300A 794694 Muffler
Used on Type No(s).
0100, 0222.
300B 794695 Muffler
Used on Type No(s).
0017, 0019, 0110,
0111, 0368.
300C 793701 Muffler
(This muffler is
intended for replace-
ment purposes only
and is not to be used
for retrofitting to
engines with different
exhaust systems)
304 791478 Housing--Blower
305 691108 Screw
(Blower Housing)
306 697240 Shield--Cylinder
309A 793524 Motor--Starter
Used on Type No(s).
0019, 0222, 0368.
309C 698311 Motor--Starter
Used on Type No(s).
0017, 0111.
318 690372 Screw
(Mounting Bracket)
332 694685 Nut
(Flywheel)
333 492341 Armature--Magneto
334 691061 Screw
(Magneto Armature)
337 491055S Plug--Spark
Used on Type No(s).
0017, 0019, 0100,
0111, 0222, 0368.
-------------- Note ----------
691043 Plug--Spark
Used on Type No(s).
0110.
355 691075 Washer
(Muffler Bracket)
356G 696748 Wire--Stop
356J 696700 Wire--Stop
358 795201 Gasket Set--Engine
362 698041 Shield--Spark Plug
363 19203 Puller--Flywheel
369 695422 Spring--Float Bowl
383 19374S Wrench--Spark Plug
410 695382 Link--Control
415 691363 Plug
436C 792374 Manifold--Exhaust
437 696705 Screw
(Exhaust Manifold)
455 697226 Cup--Flywheel
456 692299 Plate--Pawl Friction
459 281505S Pawl--Rachet
472 696752 Knob--Choke Shaft
472A 791958 Knob--Choke Shaft
474 694457 Alternator
474A 695730 Alternator
474C 698314 Alternator
474H 698230 Alternator
485 695755 Knob--Control
493 691177 Bracket--Mounting
493B 699048 Bracket--Mounting
Used on Type No(s).
0110.
501 698315 Regulator
Used on Type No(s).
0017, 0110, 0111.
503 698318 Strap--Starter
Used on Type No(s).
0017, 0111.
504 695383 Washer Set--Friction
505 691251 Nut
(Governor Control
Lever)
523 695344 Dipstick
524 691876 Seal--Dipstick Tube
525 695343 Tube--Dipstick
526 690297 Screw
(Regulator)
Used on Type No(s).
0017, 0110, 0111.
528 793006 Hose--Primer
(Cut to Required
Length)
529 791822 Grommet
552 694674 Bushing--Governor
Crank
562 793216 Bolt
(Governor Control
Lever)
564 696692 Screw
(Control Cover)
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp--Hose
604A 696758 Cover--Control
608A 699335 Starter--Rewind
Used on Type No(s).
0017, 0019, 0100,
0110, 0111, 0222,
0368.
610 794541 Arrester--Intake
613 695312 Screw
(Muffler)
613B 696705 Screw
(Muffler)
(Torx Head)
K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121A.
∆ Included in Valve Gasket Set--Ref. No. 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
