Multipiece coaxial contacts size16
UTS : Your first choice in waterproof connectors !
Technical characteristics
Ordering information
Type
RMDX
RCDX
K10
K1
D28
D28
Contact type
RMDX
RCDX
Multipiece coax kit
K10
K1
Plating
Environmental
• Operating temperature: -55°C to +125°C
Plating indication
• Retaining spring: Nickel spring
• Inner and outer contacts: D28: 0.75µm gold min. over
nickel
Connector accomodation
• Any TRIM TRIO ® size 16 contact can be used in any contact
position in any connector in the TRIM TRIO ® size 16 intercon-
nection system : UTP, UTS, UTG, UTO, MS-M, MSG / MB, SMS
Electrical
• Operating voltage between
inner / outer contact: 230 VDC
• Test potential between
inner / outer contact: 750 VAC 1 min.
• Contact retention in body: 65 N min.
• Contact voltage drop at 1A: 25m V max.
• Isolation at 30 MHZ:
140 db.
Construction
• Inner and outer contacts: High conductive copper alloy
• Insulating bushing: Thermoplastic
Kit male coax
Kit female coax
Male subminiature coax
Female subminiature coax
See plating indication
